Alternator

Part Information

Name: Alternator

Part No.: JFZ19F4

Remark:

Alternator Charge Current (A):140

Belt Pulley Diameter (mm):56

Position / Degree ():直挂

Pulley Grooves ():6PK

Voltage (V):14

OEM Number

AUDI 06J903023CX

AUDI 06D903016AX

MAZDA 32046180

VW 06B903019EX

VW 06B903016AB

VW 06B903016AF

VW 06D903023C

VW 06J903023C

VW 06B903016AA

VW 06B903016ABX

VW 06B903019E

VW 06D903016A

Reference Number

BOSCH 0986046180

BOSCH 0124525009

BOSCH 0124525088

CEVAM 4643

DELCO REMY DRB 6180

DRI 2113241402

ELSTOCK 28-4733

HELLA 8EL012429-231

HELLA 8EL738194-001

HOLGER CRISTIANSEN CA1811IR

LUCAS LEA0538

LUCAS LRA02255

MAGNETI MARELLI 944390461800

PowerMax 9212363

REMY DRB6180

VALEO SG14B010

VALEO 2542739

VALEO 542739

VALEO SG14B016

VALEO 437360

VALEO 440483

VALEO 260237A

VALEO 2606237A

VALEO 2542494

VALEO 439822

VALEO 542594

VALEO SG14FD

VALEO 2543369

VALEO 439393

VALEO SG14B022

VALEO TG14C025

VALEO 2602237

VALEO CVS082442

HERTH+BUSS 32046180

IKA 6.3182.9

LAUBER 11.1811

POWERMAX 89212363

POWERMAX 9212363

PSH 205.525.120

PSH 205.525.140

PSH 205.527.150

RS 017-120RS

WAI 11070N

WAI 23255R

WAI 23255RW

WOODAUTO ALT14162

WOODAUTO BOS0124525088

WOODAUTO VALSG12B075

WOODAUTO VALSG14B022

WOODAUTO VALTG15C065

BOSCH AL9381X

BOSCH 0 986 CR6 368

Applications

Model	Engine	Displacement	Power	Hp	Year
AUDI_A6 (4B, C5)					199701-200501
2.0	ALT	1984	96	130	200108-200501
AUDI_A6 Avant (4B, C5)					199711-200501
2.0	ALT	1984	96	130	200108-200501
AUDI_A4 (8E2, B6)					200011-200412
1.8 T	AVJ	1781	110	150	200011-200207
2.0	ALT	1984	96	130	200011-200412
1.8 T quattro	AVJ	1781	110	150	200011-200207
1.6	ALZ	1595	75	102	200011-200412
2.0 FSI	AWA	1984	110	150	200207-200412
1.8 T	BKBBFB	1781	120	163	200207-200412
1.8 T quattro	BFB	1781	120	163	200207-200412
1.8 T	BEX	1781	140	190	200211-200412
1.8 T quattro	BEX	1781	140	190	200211-200412
1.8 T	AMB	1781	125	170	200107-200412
1.8 T quattro	AMB	1781	125	170	200107-200412
AUDI_A4 Avant (8E5, B6)					200104-200412
1.6	ALZ	1595	75	102	200109-200412
2.0	ALT	1984	96	130	200109-200412
1.8 T	AVJ	1781	110	150	200109-200207
1.8 T quattro	AVJ	1781	110	150	200109-200207
2.0 FSI	AWA	1984	110	150	200207-200412
1.8 T	BFB	1781	120	163	200207-200412
1.8 T quattro	BFB	1781	120	163	200207-200412
1.8 T	BEX	1781	140	190	200211-200412
1.8 T quattro	BEX	1781	140	190	200211-200412
1.8 T quattro	AMB	1781	125	170	200109-200412
AUDI_A4 Convertible (8H7, B6, 8HE, B7)					200204-200903
1.8 T	BFB	1781	120	163	200207-200903
1.8 T quattro	BFB	1781	120	163	200305-200903
2.0	ALT	1984	96	130	200409-200512
2.0 TFSI 16V	BWTBWE	1984	147	200	200601-200903
AUDI_A3 (8P1)
2.0 TFSI	BWACAWBAXXCCZA	1984	147	200
2.0 TFSI quattro	BWAAXXCCZA	1984	147	200
1.8 TFSI	CDAABYTBZB	1798	118	160
1.8 TFSI quattro	CDAA	1798	118	160
AUDI_A3 Sportback (8PA)
2.0 TFSI	BWABPYCAWBCBFAAXXCCZA	1984	147	200
2.0 TFSI quattro	BWAAXXCCZA	1984	147	200
1.8 TFSI	CDAABYTBZB	1798	118	160
1.8 TFSI quattro	CDAA	1798	118	160
AUDI_A4 (8EC, B7)					200411-200806
2.0 TFSI	BWEBPGBWTBGB	1984	147	200	200411-200806
2.0 TFSI quattro	BPGBWEBGBBWT	1984	147	200	200411-200806
1.8 T	BFB	1781	120	163	200411-200806
1.8 T quattro	BFB	1781	120	163	200411-200806
2.0	ALT	1984	96	130	200411-200806
1.6	ALZ	1595	75	102	200411-200806
2.0 TFSI	BUL	1984	162	220	200506-200806
2.0 TFSI quattro	BUL	1984	162	220	200506-200806
2.0 TFSI	BYKBPJ	1984	125	170	200610-200806
AUDI_A4 Avant (8ED, B7)					200411-200806
1.6	ALZ	1595	75	102	200411-200806
2.0	ALT	1984	96	130	200411-200806
1.8 T	BFB	1781	120	163	200411-200806
1.8 T quattro	BFB	1781	120	163	200411-200806
2.0 TFSI	BWEBGB	1984	147	200	200411-200806
2.0 TFSI quattro	BWEBGBBWT	1984	147	200	200411-200806
2.0 TFSI	BUL	1984	162	220	200506-200806
2.0 TFSI quattro	BUL	1984	162	220	200506-200806
2.0 TFSI	BYKBPJ	1984	125	170	200610-200806
AUDI_TT (8J3)
2.0 TFSI	BWABPYCCTA	1984	147	200	200608-201006
1.8 TFSI	CDAA	1798	118	160
2.0 TFSI quattro	CCZA	1984	147	200	200806-201006
AUDI_TT Roadster (8J9)
2.0 TFSI	BWABPYCCTA	1984	147	200	200703-201006
1.8 TFSI	CDAA	1798	118	160
2.0 TFSI quattro	CCZA	1984	147	200	200806-201006
AUDI_A3 Convertible
1.8 TFSI	CDAABZB	1798	118	160
2.0 TFSI	CAWBCCZA	1984	147	200
SEAT_ALTEA (5P1)
1.8 TFSI	BYTCDAABZB	1798	118	160
SEAT_TOLEDO III (5P2)					200404-200905
1.8 TFSI	BYTBZBCDAA	1798	118	160	200701-200905
SEAT_LEON (1P1)
1.8 TSI	BZBCDAA	1798	118	160
2.0 TFSI	CCZB	1984	155	211
SEAT_ALTEA XL (5P5, 5P8)
1.8 TFSI	BYTCDAABZB	1798	118	160
2.0 TFSI 4x4	CCZB	1984	155	211
SEAT_EXEO (3R2)
1.6	ALZ	1595	75	102
1.8 T	CFMA	1781	110	150
2.0 TFSI	BWE	1984	147	200
SEAT_EXEO ST (3R5)
1.6	ALZ	1595	75	102
1.8 T	CFMA	1781	110	150
2.0 TFSI	BWE	1984	147	200
SKODA_OCTAVIA (1Z3)
1.8 TSI	CDAABZB	1798	118	160
SKODA_OCTAVIA Combi (1Z5)
1.8 TSI	BZBCDAA	1798	118	160
1.8 TSI 4x4	CDAA	1798	118	160
SKODA_SUPERB (3T4)
1.8 TSI	BZBCDAA	1798	118	160
1.8 TSI 4x4	CDAA	1798	118	160
SKODA_YETI (5L)
1.8 TSI 4x4	CDAA	1798	118	160
2.0 TDI	CFHACLCA	1968	81	110
2.0 TDI 4x4	CBDBCLCBCFHC	1968	103	140
2.0 TDI 4x4	CEGACFJA	1968	125	170
SKODA_SUPERB Estate (3T5)
31.8 TSI	CDAA	1798	118	160
1.8 TSI 4x4	CDAA	1798	118	160
VW_GOLF V (1K1)					200310-200902
2.0 GTI	AXXBWACCTACBFABPYCAWB	1984	147	200	200410-200902
VW_PASSAT (3C2)
2.0 FSI	CAWBCCZAAXXBWABPYCCTACBFA	1984	147	200	200507-201007
1.8 TSI	BZBCDAA	1798	118	160	200705-201007
VW_PASSAT Variant (3C5)
2.0 FSI	CAWBCCZAAXXBWABPYCCTACBFA	1984	147	200	200508-201011
1.8 TSI	BZBCDAA	1798	118	160	200705-201110
VW_EOS (1F7, 1F8)
2.0 TFSI	BWABPYCCTACBFACAWBCCZA	1984	147	200
2.0 TSI	CCZB	1984	155	210
VW_TIGUAN (5N_)
2.0 TFSI 4motion	CCZACAWBCCTA	1984	147	200
2.0 TFSI 4motion	CAWACCZC	1984	125	170
VW_PASSAT CC
1.8 TSI	CDAABZB	1798	118	160	200806-201011
2.0 TSI	CCTACBFACAWBCCZA	1984	147	200
VW_SCIROCCO (137)
2.0 TSI	CAWB	1984	147	200	200805-200911
2.0 TSI	CCZB	1984	155	210	200911-201105
VW_GOLF VI (5K1)
2.0 TSI	CCZB	1984	155	210
2.0 TDI	CBAACFFA	1968	100	136
1.8 TSI	CDAA	1798	118	160
VW_PASSAT (362)
1.8 TSI	CDAA	1798	118	160
VW TOURAN (1T3)
2.0 TDI	CFJA	1968	125	170
LAND ROVER_DISCOVERY I (LJ, LG)					198910-199810
2.5 TDI	12 L21 L19 L17 L	2496	83	113	198910-199810
3.9 V8	36 D35 D	3947	134	182	199309-199810
2.5 D 4x4	22 L19 L	2495	90	122	199407-199810
